High-Speed EPP Automatic Shape Molding Equipment

1. Multiple feeding methods: pulse feeding, normal pressure feeding, pressurized feeding, back pressure feeding, seamless feeding, multiple feeding, flowing air assisted feeding, etc.;
2. Adopt high-precision digital proportional valve to control feeding, heating, demoulding and other production processes, reduce energy consumption in the production process, and ensure quality;
3. Intensive hydraulic drive system, effectively combines drive and pressurization for easy maintenance;
4. Quick mold change structure: adopt rail-type quick mold change to reduce downtime and fully improve equipment utilization;
5. The machine comes with a water tank (the steam chamber is equipped with a heat insulation layer);
6. More precise seam accuracy;
7. High-rigidity frame, which can adapt to EPP industry production for a long time;
8. A variety of safety protection devices.

Products Detail

Application

Technical Data

ltem		Unit	EPP813	EPP1214	EPP1318
Mold Frame Dimensions		mm	1430X930	1530X1330	1930X1430
Rear Window Size		mm	1350X850	1450X1250	1850X1350
Effective Molding Area		mm	1200X700	1300X1100	1700X1200
Maximum Product Height		mm	400	400	400
Steam System	Steam Pipeline	DN	100	125	125
	Mold Interface	DN	40X6	40X8	40X8
	Working Pressure	Kg/cm²	5~8	5~8	5~8
Air System	Pipeline Interface	DN	65	80	80
Air System	Working Pressure	Kg/cm²	4～5	4～5	4～5
Cooling Water System	Pipeline Interface	DN	80	100	100
	Working Pressure	Kg/cm²	3～4	3～4	3～4
	Mold Interface	DN	25X6	25X8	25X8
Sewage System	Vacuum Interface	DN	100	125	125
	Fixed/Movable Drainage	DN	80	100	100
	Drain Pipe Interface	DN	125	150	150
	Mold Interface	DN	40X6	40X8	40X8
Hydraulic System	Oil Pump Motor	Kw	7.5	11	11
	Oil Pump Capacity	L/min	23+53	25+75	25+75
	Maximum Clamping Force	T	50	90	100
	Mold Opening/Closing Cylinder	mm	125X1360/2	100X1360/2	100X1360/2
	Clamping Cylinder	mm	//	125X1360/4	125X1360/4
	Demolding Cylinder	mm	50X30X450	70X40X450	70X40X450
Barrel System	Barrel Volume	m³	0.15	0.3	0.3
	Material Supply Fan	Kw	2.2	3	3
	Discharge Ports	pcs	32	50	50
Single Machine Vacuum Pump		Kw	5.5	7.5	7.5
Single Machine Power		Kw	15.2	21.5	21.5
Overall Dimensions		L×W×H	5200X2900X3100	5500X3000X3700	5800X3400X3800
Single Machine Weight		T	10	13	15
