EPS CNC Engraving Cutting Machine 4X

Hangzhou Fuyang Dongshan Plastic Machinery Co., Ltd. specialized in manufacturing EPS, EPP foam plastics machine for nearly 20 years with integrating independent R&D, manufacture, sales and service.

Category：Product Categories

Products Detail

Model	GBEC-1325-4X
Lathe body	Thick and Hard Steel structure (sandblast & seasoning)
X Y axis working area	1300*2500mm
Z axis travel	500mm
Rotary diameter	1000mm
Precision Machining	0.05mm/ 1000mm
Max Traverse Speed	30m/ min
Max processing speed	15m/ min
Table size	1400*2700mm
Resolution	0.01—0.05 mm
Spindle power rate	4 kw high speed motor,with water cooling
X. Y axis,Z structure	Flat liner /servo motor (leisai) Z axis -ball screw
Motor of rotary axis	Stepper Motor
Guide Rail	25mm
Small Electronic parts	Schneider
Spindle rotating speed	0-24000r/min
Standard Power	AC380V--Three Phase
Clamping mode	By Slots
Diameter of cutter	φ3. 175-φ16
De-duster	With de-duster

The Feature of machine:

1. Heavy Hard Steel Lath Body, keep the machine's working High stability.Whole machine is welded with seamless steel structure

2. Software

3D drawing software : ArtCAM

3X3D-4X Drawing software : Powermill , Beijing JD

Cutting system : RichAUTO A18 for 4 X file : *. NC (operation)3. Has the function of re-carving after break point and power failure.

4. Has the function of forecasting process time.

5. with oil-inject system, which makes maintenance much easier

6.Tools' Specification: You can choose different diameter and length tool according to your processing . 7.This machine can cut Wood, PVC & EPS after changing the cutting tool.

COMMISSIONING & TEST RUNING:

1.the Seller will prepared necessary material for testing and training for coating.

2. the seller will provide more photos and vedio for start up. As well as on-line service.

3.If client required, Seller will send one person to buyer`s place for start up and commission.But the buyer will cover round way ticket, accommodation , local transportation, interpreter andother necessary

things during commissioning & tests running period. Plus USD100/day per person will be charged as commission fee. Estimate commissioning & test-running periods will take about 5 working days by 1 person;
