X-B Series Fully Automatic EPS Shape Molding Machine

>>Messages

>>Contact

Mail: xu@dong-shan.cn

Product features:

Fully automatic operation: Intelligent control system covers the entire forming process, reducing manual intervention;

High-precision molding: Ensure that each EPS product has consistent size and smooth surface;

High-efficiency production: Rapid prototyping, suitable for continuous batch production and increasing production capacity;

Reliable and durable: Adopt high-quality materials and stable structure to reduce maintenance costs.

Dongfeng's X-B Series EPS Shape Molding Machine provides intelligent solutions for EPS production, significantly improving production efficiency and product quality.

The full-process automated EPS foaming equipment achieves one-time precision molding of complex geometric structures through intelligent control, greatly improving production capacity and product consistency, and is specially built for industrial fields such as packaging and building materials.

X-B series fully automatic EPS forming machine is specially designed for high-efficiency EPS production lines and is suitable for the production of large-scale foam products.

Products Detail

Equipment advantages

The machine uses a PLC programmable industrial controller and a computer touch screen to complete the automatic cycle processes of the machine such as mold opening and closing, negative pressure feeding, heating, insulation, cooling, demoulding, and product ejection;

The sheet forming speed is fast, has good adhesion, and uniform density, which avoids the disadvantages of uneven feeding density between upper and lower parts of the mold cavity of the single air chamber sheet forming machine, insufficient feeding at the corners of the sheet, and moisture in the sheet;

The machine is made of high-quality steel welded and subjected to aging treatment to make the machine have high strength and no deformation. The density of the plate produced by the machine can reach 6-45kg/m3 ;

The machine can be equipped with touch screen, automatic conveying device and automatic electronic weighing and printing device;

The machine can be matched with color steel sandwich panels to produce plates of 850mm, 950mm and 1150mm, and can also produce 1000mm building plates.

Application

Technical Data

ltem		Unit	EPS1210	EPS1412	EPS1513	EPS1750	EPS1816	EPS2216
OD of Mold		mm	1200×1000	1400×1200	1500×1300	1750×1450	1800×1600	2200×1600
Rear Window Size		mm	1100×900	1250×1100	1400×1200	1650×1350	1700×1450	2050×1450
Effective Forming Area		mm	1000×800	1200×1000	1300×1100	1550×1250	1600×1350	1950×1350
Max.Product Height		mm	400	400	400	400	400	400
Steam	Steam Pipeline	DN	100	100	100	125	125	125
	Mold Interface	DN	40×6	40×8	40×8	40×8	40×8	40×8
	Working Pressure	Kg/cm²	3~6	3~6	3~6	3~6	3~6	3~6
Air	Pipeline Interface	DN	65	65	65	80	80	80
Air	Working Pressure	Kg/cm²	4～5	4～5	4～5	4～5	4～5	4～5
Cooling Water	Pipeline Interface	DN	80	80	80	100	100	100
	Working Pressure	Kg/cm²	3～4	3～4	3～4	3～4	3～4	3～4
	Mold Interface	DN	25×6	25×8	25×8	25×8	25×8	25×8
Drainage	Vacuum Interface	DN	100	100	100	125	125	125
	Fixed and Movable Drainage	DN	80	80	80	100	100	100
	Sewage Pipe Interface	DN	100	100	100	100	125	125
	Mold Interface	DN	40X6	40X8	40X8	40X8	40X8	40X8
Hydraulic	Oil Pump Motor	Kw	5.5	5.5	5.5	7.5	7.5	11
	Size of Oil Pump	L/min	23+53	25+75	25+75	25+94	25+94	31+116
	Maximum Clamping Force	T	24	24	24	38	38	42
	Mold Opening and Closing Cylinder	mm	100×1360/2	100×1360/2	100×1360/2	125×1360/2	125×1360/2	150×1360/2
	Demoulding Cylinder	mm	50×30×450	50×30×450	50×30×450	50×30×450	50×30×450	70×40×450
Barrel	Material Barrel Capacity	m³	0.15	0.3	0.3	0.3	0.3	0.3
	Material Supplementary Blower	Kw	1.5	2.2	2.2	2.2	2.2	2.2
	Discharge Outlet	unit	32	50	50	50	50	64
Single Motor Power		Kw	7	7.7	7.7	9.7	9.7	13.2
Outer Size (LWH)		mm	5250×1750×3785	5250×1950×3785	5250X2050X3885	5430×2250×4000	5450×2230×4000	5632×2620×4100
Weight		T	4.5	5	6.5	7.5	8.5	9
